Benchcrafted Split Top Roubo Plans
This Benchcrafted Split Top Roubo bench plan is based on Andre Roubo's bench from Plate 11 of L'Art du Menuisier, with the added capabilities of the Benchcrafted vices. Benchcrafted developed this plan so woodworkers could build a bench using the Benchcrafted Tail Vice and Glide Leg Vice without having to figure out all the details. Simply follow the measured drawings and instruction notes.
The measured...
Brusso Brass Ball Catch BC-263
The Brusso BC-263 morticed ball catch, consisting of a brass cylinder with spring-loaded steel ball and a brass keeper, is used to secure cabinet doors. The grooved sides of each half, measuring 1/4" in diameter, provide grip when mounted and a reservoir for glue.
Diameter: 0.250" - 1/4" - 6mm
Brusso Brass Ball Catch BC-265
The Brusso BC-265 brass morticed ball catch, consisting of a brass cylinder with spring-loaded steel ball and a brass keeper, is used to secure cabinet doors. The grooved sides of each half, measuring 11/32" in diameter, provide grip when mounted and a reservoir for glue.
Diameter: 0.344" - 11/32" - 9mm
Brusso Brass Ball Catch BC-275
The Brusso BC-275 brass morticed ball catch, consisting of a brass cylinder with spring-loaded steel ball and a brass keeper, is used to secure cabinet doors. The grooved sides of each half, measuring 7/16" in diameter, provide grip when mounted and a reservoir for glue.
Diameter: 0.438" - 7/16" - 11mm
Brusso Brass Box Lid Stay JB-250
The Brusso JB-250 brass morticed lid support provides an elegant brass look and a functional and reliable 90 degree stop for boxes and cases. Excellent for humidor, jewellery box, and other keepsake projects.
The body is morticed into the side, and a flanged cylindrical anchor is pressure fitted and glued into the lid. The body measures 2-7/8" x 1/4" x 1/2" deep.
Length: 2.875"...
Brusso Brass Box Lid Stay JB-280
The Brusso JB-280 brass morticed lid support provides an elegant brass look and a functional and reliable 90 degree stop for boxes and cases. Excellent for humidor, jewellery box, and other keepsake projects.
The body is morticed into the side, and a flanged cylindrical anchor is pressure fitted and glued into the lid. The body measures 4-5/16" x 3/8" x 3/4" deep.
Length: 4.313"...
Brusso Brass Butt Hinge CB-301
The Brusso CB-301 full mortice butt hinge, milled from heavy brass stock, is the smallest of four versions manufactured for boxes and small cabinets. It measures 3/4" x 13/16".
Length: 0.750" - 3/4" - 19mm
Width: 0.813" - 13/16" - 21mm
Leaf Thickness: 0.086" - 5/64" - 2mm
NOTE - All Brusso hinges come in PAIRS. Screws are INCLUDED (brass for the brass...
Brusso Brass Butt Hinge CB-302
The Brusso CB-302 full mortice butt hinge, milled from heavy brass stock, is one of four versions manufactured for boxes and small cabinets. It measures 1¼" x 13/16".
Length: 1.250" - 1¼" - 32mm
Width: 0.802" - 13/16" - 21mm
Leaf Thickness: 0.086" - 5/64" - 2mm
NOTE - All Brusso hinges come in PAIRS. Screws are INCLUDED (brass for the...
Brusso Brass Butt Hinge CB-303
The Brusso CB-303 full mortice butt hinge, milled from heavy brass stock, is one of four versions manufactured for boxes and small cabinets. It measures 1¼" x 1 1/16". Available with ball finials as CB-303B.
Length: 1.250" - 1¼" - 32mm
Width: 1.063" - 1-1/16" - 27mm
Leaf Thickness: 0.085" - 5/64" - 2mm
NOTE - All Brusso hinges come in...
Brusso Brass Butt Hinge CB-407
The Brusso CB-407 full mortice butt hinge, milled from heavy brass stock, is the largest of four versions manufactured for boxes and small cabinets. It measures 2" x 1½". Available with ball finials as CB-407B.
Length: 2.000" - 51mm
Width: 1.490" - 1½" - 38mm
Leaf Thickness: 0.109" - 7/64" - 3mm
NOTE - All Brusso hinges come in PAIRS. Screws...
Brusso Brass Butt Hinge with Ball Finials CB-303B
The Brusso CB-303B full mortice butt hinge with ball finials, milled from heavy brass stock, is one of four different sizes manufactured for boxes and small cabinets. It measures 1-1/4" x 1-1/16". Available without ball finials as CB-303.
Length: 1.250" - 1-1/4" - 32mm
Width: 1.063" - 1-1/16" - 27mm
Leaf Thickness: 0.085" - 5/64" - 2mm
NOTE - All Brusso...
Brusso Brass Centre Pivot Hinge ST-12
The Brusso ST-12 brass centre pivot hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 1-3/8" x 5/16" x 3/32".
Length: 1.375" - 1-3/8" - 35mm
Width: 0.313" - 5/16" - 8mm
Leaf Thickness: 0.094"...
Brusso Brass Centre Pivot Hinge ST-18
The Brusso ST-18 brass centre pivot hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 1¾" x 3/8" x 1/8".
Length: 1.750" - 1¾" - 45mm
Width: 0.375" - 3/8" - 10mm
Leaf Thickness:...
Brusso Brass Centre Pivot Hinge ST-80
The Brusso ST-80 brass centre pivot hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 2" x 1/2" x 3/16".
Length: 2.000" - 2" - 51mm
Width: 0.500" - 1/2" - 13mm
Leaf Thickness: 0.188" - 3/16"...
Brusso Brass Centre Pivot Hinge ST-93
The Brusso ST-93 brass centre pivot cabinet hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 2½" x 5/8" x 1/4".
Length: 2.500" - 2½" - 64mm
Width: 0.625" - 5/8" - 16mm
Leaf Thickness:...
Brusso Brass Centre Pivot Hinge ST-97
The Brusso ST-97 brass centre pivot cabinet hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 3¼" x 3/4" x 5/16".
Length: 3.250" - 3¼" - 83mm
Width: 0.750" - 3/4" - 19mm
Leaf Thickness:...
Brusso Brass Chain Carousel MC-510
The Brusso MC-510 brass spinning hook with six radial arms mounts on the upper surface of a cabinet's interior. The base is pressure fit and glued into place.
The overall diameter is 1-5/8" and projects 1-1/8". The mounting dowel is 3/8" in diameter.
Brusso Brass Hook MC-437
The Brusso MC-437 brass hook, with a flattened dome face ringed by a band-shaped edge, is pressure-fit and glued into place.
It measures 3/8" in diameter and projects 15/16". The mounting dowel is 3/16" in diameter.
Brusso Brass Intermediate Offset Pivot Hinge LI-97
The Brusso LI Intermediate Offset Pivot Hinge fills the gap in their Offset Pivot Hinge line. This hinge is designed to be installed in the mid section of larger doors to provide additional strength and support. When installed inline with the L-97 Offset Pivot Hinges you receive the added benefit of an extra pivot point with the same low profile look of a Off Pivot Hinge. This hinge comes with the...
Brusso Brass Jewellery Box Feet HD-702
The HD-702 brass decorative box foot comprises a square base with a radiused inner corner and an inset block foot. The base is mortised into the bottom of the box and fastened with two screws. It measures 7/8" x 7/8" with an overall thickness of 1/4". Supplied as a set of 4.
Routing template available: TJ-702
Brusso Brass Jewellery Box Feet JB-423
The JB-423 decorative box foot, comprised of a sphere with a disC-shaped foot, is pressure-fit and glued into place. It measures 1/2" in diameter and projects 3/8". The mounting dowel is 5/16" in diameter.
Supplied as a set of 4.
Brusso Brass Jewellery Cabinet Pull MC-422
The Brusso MC-422 brass decorative knob, with a flattened dome face ringed by a band-shaped edge, is pressure-fit and glued into place. It measures 5/16" in diameter and projects 5/16". The mounting dowel is 3/16" in diameter.
Diameter: 0.303" - 5/16" - 8mm
Length: 0.305" - 5/16" - 8mm
Brusso Brass Jewellery Cabinet Pull MC-428
The Brusso MC-428 brass decorative knob, with a flattened dome face ringed by a band-shaped edge, is pressure-fit and glued into place. It measures 3/8" in diameter and projects 7/16". The mounting dowel is 3/16" in diameter.
Diameter: 0.375" - 3/8" - 9.5mm
Length: 0.436" - 7/16" - 11mm
Brusso Brass Jewellery Cabinet Pull MC-432
The Brusso MC-432 brass decorative knob, with a flattened dome face ringed by a band-shaped edge, is pressure-fit and glued into place. It measures 1/2" in diameter and projects 9/16". The mounting dowel is 5/16" in diameter.
Diameter: 0.500" - 1/2" - 13mm
Length: 0.598" - 9/16" - 14mm
Brusso Brass Latch JB-818
The Brusso JB-818 brass latch is morticed into the lid and front of a box or case up to the edge of the cove moulding. The spring-loaded pivoting bar releases the latch when the button is pressed.
Length: 1.375" - 1-3/8" - 35mm
Width: 0.500" - 1/2" - 13mm
Depth: 0.370" - 3/8" - 10mm
Routing template available: TJ-818
Brusso Brass Latch JB-828
The Brusso JB-828 brass latch is morticed into the lid and front of a box or case up to the edge of the cove moulding. The spring-loaded pivoting bar releases the latch when the button is pressed. It measures 2" x 3/4" x 3/8".
Length: 2.000" - 2" - 50mm
Width: 0.750" - 3/4" - 19mm
Depth: 0.370" - 3/8" - 10mm
Routing template available: TJ-828
Brusso Brass Lift-Off Hinge - Left Hand - LH-201LH
The Brusso LH-201 brass heavyweight lift-off cabinet butt hinge with two knuckles is suitable for doors with a thicknesses between 3/4" and 1". It measures 2½" x 1¾". This hinge is handed; a right-hand hinge is shown.
Length: 2.500" - 2½" - 64mm
Width: 1.750" - 1¾" - 45mm
Leaf Thickness: 0.104" - 7/64" - 3mm
Packs...
Brusso Brass Lift-Off Hinge - Right Hand - LH-201RH
The Brusso LH-201 brass heavyweight lift-off cabinet butt hinge with two knuckles is suitable for doors with a thicknesses between 3/4" and 1". It measures 2½" x 1¾". This hinge is handed; a right-hand hinge is shown.
Length: 2.500" - 2½" - 64mm
Width: 1.750" - 1¾" - 45mm
Leaf Thickness: 0.104" - 7/64" - 3mm
Packs...
Brusso Brass Offset Pivot Hinge L-19
The Brusso L-19 brass offset pivot hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 5" x 3/4" x 3/8".
Length: 5.000" - 5" - 127mm
Width: 0.750" - 3/4" - 19mm
Leaf Thickness: 0.375" - 3/8"...
Brusso Brass Offset Pivot Hinge L-23
The Brusso L-23 brass offset pivot hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 1-3/8" x 5/16" x 1/8".
Length: 1.375" - 1-3/8" - 35mm
Width: 0.313" - 5/16" - 8mm
Leaf Thickness: 0.125"...
Brusso Brass Offset Pivot Hinge L-37
The Brusso L-37 brass offset pivot hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 1¾" x 3/8" x 1/8".
Length: 1.750" - 1¾" - 44mm
Width: 0.375" - 3/8" - 9mm
Leaf Thickness: 0.125"...
Brusso Brass Offset Pivot Hinge L-39
The Brusso L-39 brass offset pivot hinge is employed when a minimum of visible hardware is desired, or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 1¾" x 3/8" x 1/8". The L-39 has a longer knuckle for wide throw conditions.
Length: 1.750" - 1¾" - 44mm
Width:...
Brusso Brass Offset Pivot Hinge L-87
The Brusso L-87 brass offset pivot hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 2" x 1/2" x 3/16".
Length: 2.000" - 2" - 51mm
Width: 0.500" - 1/2" - 13mm
Leaf Thickness: 0.188" - 3/16"...
Brusso Brass Offset Pivot Hinge L-93
The Brusso L-93 offset pivot hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 2½" x 5/8" x 1/4".
Length: 2.500" - 2½" - 64mm
Width: 0.625" - 5/8" - 16mm
Leaf Thickness: 0.250"...
Brusso Brass Offset Pivot Hinge L-97
The Brusso L-97 offset pivot hinge is employed when a minimum of visible hardware is desired or when the door must swing free of its frame. It is morticed into the top and bottom of the door and frame; only the pivot is visible. The leaf measures 3¼" x 3/4" x 5/16".
Length: 3.250" - 3¼" - 83mm
Width: 0.750" - 3/4" - 19mm
Leaf Thickness: 0.313"...
Brusso Brass Quadrant Hinge HD-638
The Brusso HD-638 brass quadrant hinge is engineered with a built-in stop that allows a lid to remain open at 95°. The arc is morticed into the side of the box, beneath the leaf. The hinge is sold in pairs. Each leaf measures 1¼" x 1".
Length: 1.240" - 1¼" - 31mm
Width: 1.000" - 1" - 25mm
Leaf Thickness: 0.083" - 5/64" - 2mm
Note -...
Brusso Brass Quadrant Hinge HD-680
The Brusso HD-680 brass quadrant hinge is engineered with a built-in stop that allows a lid to remain open at 95°. The arc is morticed into the side of the box, beneath the leaf. The hinge is sold in pairs. Each leaf measures 1½" x 2".
This hinge ships unassembled with a link connecting the two leaves. When assembling, the end with the pin will go into your lid.
Length:...
Brusso Brass Recessed Pull CP-125
The Brusso CP-125 brass minimalist recessed pull is designed for cabinets and fine furniture. It may be either surface or flush mounted. The pull measures 1¼" in diameter.
Diameter: 1.250" - 1¼" - 32mm
Depth: 0.500" - ½" - 13mm
Brusso Brass Recessed Pull CP-150
The Brusso CP-150 brass minimalist recessed pull is designed for cabinets and fine furniture. It may be either surface or flush mounted. The pull measures 1½" in diameter.
Diameter: 1.500" - 1½" - 38mm
Depth: 0.500" - ½" - 13mm
Brusso Brass Recessed Pull CP-200
The Brusso CP-200 brass minimalist recessed pull is designed for cabinets and fine furniture. It may be either surface or flush mounted. The pull measures 2" in diameter.
Diameter: 2.000" - 2" - 51mm
Depth: 0.500" - ½" - 13mm
Brusso Brass Shelf Pin K-10
The K-10 brass shelf support pin comprises a decorative turned support and a cylindrical peg, which fits into the K-2 sleeve. The peg measures 1/4" in diameter x 3/8" deep, and the support projects 7/16". Supplied as a set of 4.
Brusso Brass Shelf Sleeves K-2
The K-2 brass heavy-walled shelf support sleeve is mortised flush into the side of a case, providing an anchor for the K-10 shelf support pin. The sleeve measures 3/8" in diameter x 7/16" deep. Supplied as a set of 12.
Brusso Brass Side Rail Hinge SR-638
The Brusso SR-638 brass square knuckled full mortice side rail hinge is engineered with a built-in stop that allows a lid to remain open at a 95° angle. These hinges are milled from 1/4" thick solid brass stock to precise dimensions and are designed to last a lifetime. They feature stainless steel hinge pins and the standard Brusso burnished finish. The leaf measures 5/16" wide x 1-3/8"...
Brusso Brass Side Rail Hinge SR-680
The Brusso SR-680 brass square knuckled full mortice side rail hinge is engineered with a built-in stop that allows a lid to remain open at a 95° angle. These hinges are milled from 1/4" thick solid brass stock to precise dimensions and are designed to last a lifetime. They feature stainless steel hinge pins and our standard Brusso burnished finish. The leaf measures 1/2" wide x 2"...
Brusso Brass Stop Hinge JB-101
The Brusso JB-101 brass square knuckled full mortice butt hinge is engineered with a built-in stop that allows a lid to remain open at 95°. It is milled from heavy brass stock and can be used when an additional stay is not desired. The leaf measures ¾" in length.
Length: 0.750" - 3/4" - 19mm
Width: 0.495" - 1/2" - 12mm
Thickness: 0.187" - 3/16" -...
Brusso Brass Stop Hinge JB-102
The Brusso JB-102 brass square knuckled full mortice butt hinge is engineered with a built-in stop that allows a lid to remain open at 95°. It is milled from heavy brass stock and can be used when an additional stay is not desired. The leaf measures 1¼" in length.
Length: 1.250" - 1¼" - 32mm
Width: 0.495" - 1/2" - 12mm
Thickness: 0.187" - 3/16"...
Brusso Brass Stop Hinge JB-103
The Brusso JB-103 brass square knuckled full mortice butt hinge is engineered with a built-in stop that allows a lid to remain open at 95°. It is milled from heavy brass stock and can be used when an additional stay is not desired. The leaf measures 1¼" in length.
Length: 1.250" - 1¼" - 32mm
Width: 0.618" - 5/8" - 16mm
Thickness: 0.187" - 3/16"...
Brusso Brass Stop Hinge JB-107
The Brusso JB-107 brass square knuckled full mortice butt hinge is engineered with a built-in stop that allows a lid to remain open at 95°. It is milled from heavy brass stock and can be used when an additional stay is not desired. The leaf measures 2" in length.
Length: 2.000" - 51mm
Width: 0.870" - 7/8" - 22mm
Thickness: 0.250" - 1/4" - 6mm
Leaf Thickness:...
