Inlay Straight-Line Cutter
Product Description
The Latta Straight-Line Cutter by Red Rose Reproductions
Used to cut straight grooves parallel to the sides of the workpiece. Comes with two cutters: one for cross grain and one for with the grain cutting.
Hard Maple body with an oil finish.
About the Inlay Tools
Red Rose Reproductions were approached by Lie-Nielsen in 2023 asking whether they would be interested in taking over their line of inlay tools. These tools are designed specifically for stringing inlay, a popular decorative technique in Federal pieces, along with certain regional furniture, particularly southeast Pennsylvania, from the 18th century. Educator/cabinetmaker Steve Latta, the original inspiration of these tools, offered input and encouragement as they worked to bring them back to the market. Stringing inlay is when veneer of a different species, usually holly, is cut and sized into thin strips and let into grooves cut into the work. Various patterns and designs can be created, and even lettering.
The process of doing stringing inlay starts with veneer, either shop cut or commercial. The veneer is first cut into strips, called stringing, that are a bit wider than the groove will be deep, usually around 1/8'' (3.2mm). Next, these strips are passed through a thicknessing gauge to get them to a precise thickness to fit into the grooves in the work.
Grooves are cut into the work using either the radius gauge, for grooves on a radius, or the straight-line cutter for grooves parallel to the edges of the work. Once the grooves are cut and the stringing is prepared, the stringing is glued into the grooves with yellow glue. After the glue is set, excess stringing is trimmed flush with the work.
There are four tools offered by Red Rose Reproductions as described below:
- Slicing gauge. This tool is used to slice veneer into thin strips to form pieces of stringing. It works much like a marking gauge, and can, in fact, be used for that purpose just as well. This is the only tool that is not ambidextrous, so it is available in both right-hand and left-hand versions to suit the user’s preference.
- Thicknessing gauge. Used to trim stringing to a precise thickness to fit into the grooves made by the radius cutter and straight-line cutter. This tool has two cutters, and one can be set up to get the stringing close to size, and the other for the final sizing.
- Radius cutter. Used to cut grooves to receive stringing on a radius. It can cut a radius from 11/16'' (17mm) to 4'' (100mm). With the optional extension rods, it can cut any size radius required. Each pair increases the maximum radius that can be cut by 3'' (76mm). Comes with two pivot points of different heights.
- Straight-line cuter. Used to cut straight grooves parallel to the sides of the workpiece. Comes with two cutters: one for cross grain and one for with the grain cutting.
The standard cutters for the radius gauge and the straight-line cutter are .031'' (0.79mm) thick. They plan to offer other thicknesses in the near future, allowing for different widths of stringing to be used. Cutters on all tools are made of 1095 spring steel, hardened to Rc 52. All are sharpened, but the thicknessing gauge should have a burr turned on the cutters for best performance.
The radius cutter body is black anodizes aluminum, and the other wood tools are made of hard maple with an oil finish. Other components are brass stainless steel, and steel.
Working with Steve Latta, they plan to offer more information about these tools in the form of videos.
Also, we recommend streming the video by Steve Latta, “Fundamentals of Inlay; Stringing, Line & Berry”. Available at Lie-Nielsen Toolworks.
About Red Rose Reproductions
Red Rose Reproductions LLC was created in 2014 with an objective to bring resurrected woodworking tools to the market. Daniel R. Schwank, company founder, has made many tools for his own use, and decided that others may appreciate them too. Red Rose Reproductions focuses primarily on moulding planes patterned off mid 18th century British designs. Offerings also have branched into other bench tools and work holding devices.
In October 2017, Dan gave up his work as a tool and die maker to pursue the business full time. He makes a number of his tool offerings in batches and offers them primarily through this web site and tool shows. Some tools, such as hollow and round moulding planes, are generally made to order. He also teaches classes on making hollow and rounds in his shop, which is now relocated in Sterling IL.
Dan’s interest in furniture began with his marriage in 1994, when he was introduced to woodworking by his Father-In-Law. Thus began a journey to build his skill levels and knowledge of furniture design and construction, and later hand tools. As a tool & die maker, Dan found woodworking and tool making to require many of the same skills and approaches to tasks as metal working does. This also made it a natural transition into making tools.
Dan is primarily self taught, although he has taken quite a few classes devoted to 18th century furniture styles and construction techniques, and plane making with Tod Herrli and with input from Larry Williams of Old Street Tool. His approach is a combination of both modern machinery and traditional hand tools, although with plane making, most of the work is done by hand.
Red Rose Reproductions, located in Sterling IL, is modest but well equipped. A lot of effort has been put into keeping the overhead down while at the same time striving to work as efficiently as possible. The result is pricing that is very competitive yet of high quality.
